SS 304 Storage tank with agitator
Capacity: 1000 Litre
State
New
Quantity
1
Capacity size
1,000 liter
Material
SS 304
Empty weight
350 kg
Working pressure
0 bar
Foundation
SS legs
Number of legs
4
Modell bottom head
Flat bottom with slope
Modell top head
Conical
Brand
Jongia
Type
JDR 05/6
Kind
Propeller
Diameter propeller
200 mm
Number of agitators
1
Location drive
On top
Speed
460 rpm
Engine power
0.3 kW
Inside diameter
1,000 mm
Outside diameter
1,000 mm
Cylindrical height
1,250 mm
Total height
2,100 mm
Leg length
250 mm
Outlet height
235 mm
Wall thickness bottom
2.5 mm
Wall thickness cylinder
2.5 mm
Wall thickness roof
3 mm
Outlet
50 mm
Inlet
50 mm
Breather vent
100 mm
Type of breather vent
With cap
CIP connection
38 mm
Type of CIP
Spray ball
Manhole
400 mm
Place manhole
On top
